Technical Highlights
- Proprietary R2R + DSD Architecture
- True balanced 24BIT R2R + 6BIT DSD (32 steps FIR Filters)
- Native DSD decoding with 0.01% precision resistors
- Encapsulated Ultra Low Noise Power Supply
- Amanero USB Interface
- Ultra Low Jitter Digital Receiver AK4118
- Adaptive FIFO Buffer Reclocking
DSD
- 2.8224MHz(DSD1X) On All Input
- 5.6448MHz(DSD2X), 11.288MHz(DSD4X) On USB & I²S Input Only
PCM
- 24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
- 24bits / 352.8, 384kHz On USB & I²S Input Only
Sampling Mode: Non-Oversampling NOS / Oversampling OS
Digital Input
- Coax 1 via RCA
- Coax 2 via BNC 75 Ω
- TOSLink x 1
- AES/EBU x 2
- USB
- I²S via HDMI LVDS / RJ45 LVCMOS
Analog Output
- RCA at 2.2Vrms, 625 Ω
- XLR at 4.4Vrms, 1250 Ω
Frequency Response: 20-70KHz -3dB
THD+N: 0.0025%
S/N Ratio: 120dB
Dynamic Range: >121dB
Stereo Crosstalk: -110dB
AC Power Requirement: 110-240VAC, 50/60Hz (Worldwide Voltage)
Power Consumption: ≤20W
Dimension: 320 x 330 x 80 mm
Package Dim: 470 x 440 x 175 mm
Weight: 8.5 Kg
Color: Silver / Black
Warranty: 36 Months
